Allied Components

EE16 Horizontal Mount / AEE16-3662

$0.00
  • EE16 Core Design
  • Through Hole
  • Vertical Mount for Smaller Foot Print
  • Flyback Topology
  • 3KVrms Hi-pot Rating
  • 18mm Max Ht
  • Operating Temperature -40ºC ~ +130ºC
Part Number

Specifications
  • Pins: 10
  • Op Temp Range: -20°C to +85°C
  • Length: 0.807 / 20.498
  • Width: 0.710 / 18.034
  • Geometry: EE16
  • Mounting Type: Through-Hole
  • Primary Inductance: 991mH
  • Turns Ratio: 21:1
  • Height: 0.630 / 16.002
    • Download Datasheet
